Product Description
HAMMOND MANUFACTURING N1A36247 NEMA BOX 36X24X7 EMPTY STEEL NEW N1A Series Panel Enclosure
Non-Ventilated - NEMA 1
<< Product Information << Commercial Enclosures <<
Application
" Designed for indoor use to house controls, instruments and components not requiring oil-tight or dust-tight protection.
Standards
" UL 50 Type 1
" CSA Type 1
" Complies with
o NEMA Type 1
o IEC 60529, IP20
Construction
" Enclosure is formed and spot welded from 12 or 14 gauge steel.
" Removable 12 or 14 gauge inner panel is mounted in the rear of the enclosure on collar studs.
" Removable door is mounted on slip hinges.
" Door is fastened with a slotted quarter turn latch; doors 30" and higher are provided with two latches.
" A bonding stud is provided on the door and a grounding stud is provided in the box.
" Mounting holes are provided in the rear of the enclosure.
" Piano hinge on 12 gauge units.
Finish
" Enclosure and door are finished in ANSI 61 gray powder coating.
" Inner panel is finished in white powder coating.
